Cut to Length Lines
Thickness
Coil Width
Cutting Length
Coil Weight
Coil Internal Diametre
Coils External Diametre
Max. Cutting Speed
Leveller workroll diametre
Leveller number of workroll
Cut to length tolerance
Line straight cut capacity
Line scroll cut capacity
Rolling width cutting (per side)
Power
LITTELL-2 STRAIGHT/SCROLL
(6 HIGH Leveller)
Min
0,125 mm
600 mm
460 mm
380mm
915mm
120 kw
Max
0,525 mm
1250 mm
1200 mm
13,6 ton
420mm
1830mm
137 m/min;
175 sheet/min
38 mm
16 pieces
-0+0,36 mm
62 kt
42 kt
LITTELL-3 STRAIGHT/SCROLL
(SCHNUTZ Leveller)
Min
0,125 mm
600 mm
559 mm
380mm
914mm
120 kw
Max
0,525 mm
1250 mm
1206,5 mm
13,6 ton
420mm
1830mm
137 m/min;
175 sheet/min
25 mm
23 pieces
-0+0,36 mm
62 kt
42 kt
FIMI Cut to Length STRAIGHT
(FIMI Leveller)
Min
0,13 mm
465 mm
450 mm
380mm
10mm
240 kw
Max
0,70 mm
1250 mm
1200 mm
16 ton
420mm
1930 mm
120m/min
32 mm
23 pieces
-0+0,60 mm
45 kt
230 mm
Slitting Lines
Thickness
Coil/Strip (entry) Width
Coil/Strip (entry) Internal Diametre
Coil/Strip (entry) External Diametre
Coil/Strip (entry) Weigth
Coil/Strip (exit) Width
Coil/Strip (exit) Internal Diametre
Coil/Strip (exit) External diametre
Slitting tolerance
Max. Cutting Speed
Line capacity
Power
STRIP COIL LINE (WIDE COILS)
Min
0,13 mm
30 mm
380mm
20 mm
400 mm
100 kw
Max
2 mm
1250 mm
420 mm
1600 mm
12 ton
1250 mm
508 mm
1600 mm
-0+0,20 mm
100m/min
24 kt
STRIP COIL LINE (NARROW COILS)
Min
0,13 mm
20 mm
380mm
8 mm
420 mm
35 kw
Max
1 mm
450 mm
508 mm
1400 mm
1,5 ton
450 mm
420 mm
1400 mm
-0+0,20 mm
100m/min
1,5 kt
New Investment H1 2020 - Cut To Length Line
Thickness
Coil Width
Cutting Length
Coil Weight
Coil Internal Diametre
Coils External Diametre
Max. Cutting Speed
Leveller workroll diametre
Leveller number of workroll
Cut to length tolerance
Line straight cut capacity
Line scroll cut capacity
Rolling width cutting (per side)
Power
RIZZATO STRAIGHT
(FIMI Rotary Shear / 4 HIGH Leveller)
Min
0,5 mm
300 mm
400 mm
270 kw
Max
2,5 mm
1500 mm
5000 mm
15 ton
508 mm
1700 mm
60 m/min;
45 mm
16 pieces
+/- 1 mm
60 Kt/Year
New Investment H1 2020 - Slitting Line
Thickness
Coil/Strip (entry) Width
Coil/Strip (entry) Internal Diametre
Coil/Strip (entry) External Diametre
Coil/Strip (entry) Weigth
Coil/Strip (exit) Width
Coil/Strip (exit) Internal Diametre
Coil/Strip (exit) External diametre
Slitting tolerance
Max. Cutting Speed
Line capacity
Power
B & V / NN SLITTING LINE
Min
0,5 mm
300 mm
380 mm
20 mm
220 kw
Max
3,5 mm
1700 mm
508 mm
1900 mm
25 ton
1690 mm
508 mm
1700 mm
-0/+0,20 mm
100 m/min
70 Kt/Year
